Sinotruk Homan SANYI Truck Mounted Telescopic Crane 5 6 7 Tons

Büyük resim : Sinotruk Homan SANYI Truck Mounted Telescopic Crane 5 6 7 Tons

Ürün ayrıntıları:

Menşe yeri:	Suizhou, Çin
Marka adı:	CLW
Sertifika:	ISO, CCC
Model numarası:	CLW527UD

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 Adet
Fiyat:	negotiable
Ambalaj bilgileri:	Toplu gemiyle gönderilen çıplak paket
Teslim süresi:	Peşin ödeme alındıktan 30 gün sonra
Ödeme koşulları:	L/C, T/T, D/P, T/T, Western Union, MoneyGram, D/A
Yetenek temini:	300 adet/ay

İletişim

Detaylı ürün tanımı

Kamyon markası:	İsteğe bağlı	Vinç markası:	Seçenek için XCMG, SANY, PALFINGER, CLW
Vinç türü:	Teleskopik / Katlanır Vinçli kamyon	Yükleme kapasitesi:	5ton/6ton Kargo Kamyona Monte Vinç
MOTOR:	190hp	Sürüş Modeli:	LHD,RHD
Maks. vinç kapasitesi:	6ton 7ton Kargo Kamyona Monte Vinç	Aks:	2
Maks. Kaldırma yüksekliği:	27,2 metre	Uygulama:	Ekskavatör ve diğer makinelerin taşınması
Vurgulamak:	7Tons Truck Mounted Telescopic Crane , SANYI Truck Mounted Telescopic Crane

Sinotruk Homan SANYI 5,6,7 Tons Truck Mounted Telescopic Crane

Product description

---- Single cylinder synchronization guy cable technology makes work efficiency much higher than before.

---- Advanced development means make sure that the design is very reliable.

---- The more symmetrical center design of pentagon & hexagon boom make it has bigger anti-bending capacity.

---- Compact hinge point design take up smaller space

---- The work is more safety after fitted over-winds alarm equipment.

---- The integer lifting winch improved the work efficiency greatly and prolonged work lift of hydraulic system.

---- Float three-point bridge structure design can lower the accessional stress on the chassis when traveling.

---- Self-designed & developed slewing machine with greater drive force can meet varied requirements of working situation.

---- Anti-slewing impulse equipment that make vehicle running safely

Specification

Sinotruk Homan 6-wheel Truck with 6Tons SANY Crane
General	Chassis brand	Homan
	Overall Dimension	7750 * 2490 * 3550 mm
	GVW	14060kg
Cab	Cabin type	Half of row cabin,3 persons with one sleeper
Cab	Air conditioner	Optional
Engine	Engine Model	WEICHAI
	Engine Power	190HP (140KW)
	Displacement	4088 ml
	Emission standard	Euro 4
Chassis	Wheelbase	4200 mm
	Driving Type	4X2,LHD&RHD
	Max.speed	89km/h
	Gear box	FAST 8-peed forward and 1 reverse
	Tire	8.25R20,6 pcs with one spare
Superstructure	Cargo Box Dimension	47202300550 mm
	Crane Type	Telescopic boom crane
	Crane brand	SANY
	Max Lifting Capacity	6300 kg
	Slewing Angle	360° All rotation
	Crane Weight	3000 kg
	Installation Space	400 mm
	Control panel	English or Your language
Optional	1-knuckle boom crane/folding arm crane; 2-Hydraulic tipper box; 3-Customized box thickness; 4-Remote control box

Our Factory

Sinotruk Homan SANYI Truck Mounted Telescopic Crane 5 6 7 Tons 0

Sinotruk Homan SANYI Truck Mounted Telescopic Crane 5 6 7 Tons 1

Sales Service

① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.

Warranty

1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
