Ürün ayrıntıları:
Ödeme & teslimat koşulları:
|
| Kutu malzemesi: | Fiberglas veya paslanmaz çelik | İsteğe bağlı kısım: | Et Kancası, Hava Kanalı, Yan Kapı, Arka Platform |
|---|---|---|---|
| Malzeme: | fiberglas panel | Yalıtım katmanı: | 8cm Poliüretan Köpük |
| Kamyon Soğutma Ünitesi: | Termoking, Taşıyıcı veya Çin Alternatifi | Uygulanabilir sıcaklık: | -18~0 |
| kutu türü: | 3 Katlı Sandviç | Dış Katman: | FİBER CAM |
| Orta katman: | 8mm PE Köpük Yalıtım | İç katman: | Fiberglas veya paslanmaz çelik |
| Yükleme kapasitesi: | 1Ton, 2Ton, 1 ton, 2 ton, 1MT, 2MT | Motor Tipi: | Benzinli motor |
| Tekerlekler: | 4 tekerlek | ||
| Vurgulamak: | LHD Small Refrigerator Truck,2T Small Refrigerator Truck,Freezer Box Truck |
||
China brand 4 wheels 2Tons Gasoline Engine Small Refrigerator Truck Freezer Box Truck Frozen Refrigerated Truck
Description:
1. Purpose: It used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.
2. Main parts: Refrigerating unit and control system.
3. Features: International chassis brand and International refrigerating unit brand for optional.
Advantages of Insulated Freezer Van body:
The advantages of Insulated/Freezer Van Body
1. It is made of GRP and PU foam with all-closed structure that the GRP (Glass Reinforced Plastic Fiber) outside
and PU foam in the core.
2. Light in weight: 40% lighter than metal body.
3. Non-corrosion, non-pollution, anti-brine, acid and soda-resisting.
4. The panel used for the truck body was constructed in type of sandwich. The thermal insulation layer is 50-80mm
thick, which offers a very good thermal insulation performance.
5. Length of Cargo body: 10-40 inch; Capacity of Cargo body: 5-70CBM. The material of the cargo body is optional
according to which kinds of goods the truck transport, with perfect heat preservation, box open model:
Rear double-open or Side-open.
6. Refrigeration unit Brand Optioanl: American CARRIER, THERMO KING. South Korea hanya. China Songhan,
hanxue, etc. The Temperature range can be 0° C ~ -20° C. The refrigeration units that we select have simple
structure, convenient operation, reliable working, low energy consumption, large refrigerating capacity, small noise,
easy installation and maintenance and other advantages.
Speicfiation:
| No. | Item | Unit | Specification |
| 1 | Vehicle Name | Foton G7 2Ton 3Ton refrigerated truck | |
| 2 | Drive type | 4*2 | |
| 3 | Steering type | Left hand drive | |
| 4 | Gross Weight | kg | 3150 |
| 5 | Payload | kg | 680 |
| 6 | Wheelbase | mm | 3050 |
| 7 | Overall Dimension | mm | 5320*1695*2500 |
| 8 | Van body size | mm | 5320*1695*2500 |
| 9 | Insulating layer thickness | cm | 8 |
| 10 | Van material | Fiberglass reinforced | |
| 11 | Refrigerator unit brand | Thermoking or Carrier | |
| 12 |
Refrigeration temperature range( degree centigrade) |
-18 to 0 | |
| 13 | Chassis Model | BJ6539B1PVA | |
| 14 | Chassis Brand | Foton | |
| 15 | Engine Model | 4Q20M | |
| 16 | Displacement / Power | ml/kw | 1998/ 95KW/ 129HP |
| 17 | Emission Standard | Euro 5 | |
| 18 | Fuel Type | Gasoline | |
| 19 | Tyre specification | 195R15C |
More Pictures:
![]()
![]()
![]()
![]()
FAQ:
