China Dayun 4x2 3T Road Recovery Flatbed Wrecker Truck

Büyük resim : China Dayun 4x2 3T Road Recovery Flatbed Wrecker Truck

Ürün ayrıntıları:

Menşe yeri:	SUIZHOU. HUBEI, ÇİN.
Marka adı:	CLW
Sertifika:	CCC, ISO9001, SGS, BV
Model numarası:	CLW2020805

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 set
Fiyat:	Negotiated
Teslim süresi:	40 iş günü
Ödeme koşulları:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Yetenek temini:	Ayda 50 adet.

İletişim

Detaylı ürün tanımı

Ürün adı:	Dayun marka tamirci kurtarma kurtarma çekici kamyon	Kamyon markası:	Sinotruk HOWO, SHACMAN, FAW, FOTON, JAC vb.
Sürücü modeli:	4X2, 6 Tekerlekli, 6 tekerlekli	Sürücü tipi:	Sağdan Direksiyonlu veya Soldan Direksiyonlu.
Max. Maks. Loading weight yükleme ağırlığı:	3000KG, 5000KG, 3 TON, 5 TON,	Teçhizat:	Hidrolik pompa, Yağ Silindiri
Ana bölümler:	Bom, Kaldırma, Vinçler, İniş Ayağı	Tel halat:	25 metre
Renk:	Pembe
Vurgulamak:	China Dayun Flatbed Wrecker Truck , 3T Flatbed Wrecker Truck , 4x2 Road Recovery Tow Truck

China Dayun 4*2 3 tons Towing Truck Small Road Recovery Flatbed Wrecker Truck

Product Description:

1. Purpose of 4ton flatbed tow truck: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
2. Optional brand of 4ton flatbed tow truc:howo,Dongfeng,Isuzu,JAC,JMC,Foton,Shacman.
3. Spare parts of 4ton flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
4. Capacity range of flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
5. The customers can choose to install the crane.

1) 5Tons Wrecker Truck for Towing Broken Cars or Equipments.

2) Dayun Brand Chassis for Euro 2 or Euro 3 Emission

3) Spare parts of 5tons wrecker tow truck:

Italy brand multi-way valve and balance valve;
Gernamy Roxroth technology hydraulic cylinder and joint;
International Brand Sealing elements;
Strengthed Checked platform.

Specification:

General Technical Specification
Overall Dimension				5995x2300x2350(mm)
Gross Vehicle Weight				4495 (Kg)
Curb Weight				3790(Kg)
Chassis Specification
Chassis Brand			Dayun Brand
Drive model			4*2
Cabin			Single, Left Hand Drive
Engine	Model		4-stroke direct injection, 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
	Power		105KW/143HP
	Emission standard		EURO2 or 3
	Displacement		3856(ml)
	Fuel type		Diesel
Gearbox			6 Forwards & 1 Reverse, Power steering, hydraulic steering with power assistance
Brake System			Pneumatic(Air break/exhaust brake)
Wheel Base			3280(mm)
Front/Rear Axle Loading			2500/4800(Kg)
Approach/Departure Angle			24/12(°)
Tire			7.00R16, 6pcs + 1 spare tire
Max Driving Speed			98(km/h)
Superstructure Specification
Platform Organ		Dimension			4200*2320(mm)
		Rear manual flip board length			1200(mm)
		Material			Q235 carbon steel
		Max Loading capacity			4000(kg)
Winch		Quantity			1
		Winch rating towing capacity			4000(kg)
		Length of steel rope			25(m)
		Speed of winch			3.23~8 (m/min)
Other parts		Auxiliary wheels, alarm light, hooks, 4 bundling belt, automatic sliding plate, etc.
Options		Caution light, air condition,inlet valve.

CLW group, which was appointed by the Development and Reform Committee of China is a professional company who deal in
different kinds of special vehicles, trailers and construction machinery.

Certificate: ASME, ISO, BV, SGS, CCC etc.
More than 30 independents workshops.
1000 sets of equipment, 25 assemble lines.
300 senior engineers and technicians. About 8000 workers.
800kinds of LPG, trucks and semi-trailers.
20 years wholesale experience
Turnover 250 million and Export 20million annually
Turnover 2 billion trucks and semi-trailers annually.
Trucks and trailers Sold to 90 countries
Cooperates DONGFENG,SINOTRUCK,ISUZU,FOTON,FAW,BEIBEN,ETC

Sales Service

① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
