EURO II LHD 5m3 Hydraulic Compression Garbage Truck

Büyük resim : EURO II LHD 5m3 Hydraulic Compression Garbage Truck

Ürün ayrıntıları:

Menşe yeri:	Suizhou, Çin
Marka adı:	CLW
Sertifika:	CCC,ISO
Model numarası:	CLW52587xzc

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 Adet
Fiyat:	negotiable
Ambalaj bilgileri:	Çıplak paketleme, Ro-ro, Toplu Gemi
Teslim süresi:	20-30 gün
Ödeme koşulları:	L/C, T/T, D/P, D/A, Western Union,, MoneyGram
Yetenek temini:	Aylık 500Birim

İletişim

Detaylı ürün tanımı

marka:	KAIMA,DONGFENG, FAW,FOTON, HOWO, JAC, JMC, ISUZU	Sürücü tekerleği:	4x2
Çöp konteyneri malzemesi:	Q345B, yüksek yoğunluklu karbon çeliği	Kalınlık:	Hem yan hem de alt kap için 4 mm
Bileşenler:	Yükleme, Sıkıştırma, Boşaltma	Kamp Etki Oranı:	0,6-0,7 Ton/Cbm
İşletim Sistemi:	Biri Kabinde, Biri Kamyonun Arkasında	Kullanım:	Ev içi çöp taşımacılığı
Garanti:	büyük parçalar için bir yıl	operasyon videosu:	Evet, seçim için Çoklu dil ile
Teknik destek:	20 yıllık deneyimli mühendis ihtiyaç duyduğunuzda size yardımcı olacaktır	Logo:	Müşterinin talebine göre
Vurgulamak:	5m3 Compression Garbage Truck , LHD Compression Garbage Truck , Hydraulic Garbage Compactor Truck

5m3 Compression Garbage Trucks Hydraulic Garbage Compactor Truck

Garbage compactor truck is composed of garbage box, hydraulic system and operating system, which is designed to load and transport more garbage by compression domestic garbage. Dirty liquid was saved in waste sink, perfectly preventing pollution. When arriving at destination, the garbage tank will discharge by one button operation. It is mostly wide used garbage truck all over the world.

Specifications of 5m3 Compression Garbage Truck

Dongfeng 6CBM Compressed Garbage Truck
Overall Dimension	6220 ×2050×2570 mm	Gross Vehicle Weight		8275 kg
Curb Weight	4350 kg	Loading Weight		1830 kg
Wheel Base	3308 mm	Front / Rear Axle		1800 kg / 3500kg
Cabin	Left Hand Driving, 2/3 Passengers Allowed, with Air Conditioner, Radio
Engine	Chaochai
Engine horsepower	98HP, EURO II
Max Driving Speed	90 km/h
Gear Box	5 Forward Gear, 1 Reverse Gear,
Tire	7.00R16 (6 pieces with one spare)
Garbage Bin	Capacity		5CBM
	Material		Q345B, 4mm Carbon Steel for Garbage Bin Body
	Design		Whole unit with Leakage Proof Design
Ways of Loading	Rear Loading with optional Bucket Lifting System
Garbage Compact Ratio	0.6 - 0.7
Control System	One control Panel on the back, One Control system in back of Cabin
Working System	1. Equipped with air-tight dustbin, hydraulic system and operating system.
	2. Automatic loading, compressing and discharging, all handled by 1 person
	3. Sewage water collection tank to avoid any pollution during handling.
	4. Large Pressure, Good Leakage Proof, Convenient Operation
	Dependable Security
	5. Electrical Control Panel for compacting system.
	6. Cycling time＜14~18s
Remarks	1. Color is optional
	2. Customized LOGO painting as per customer request

EURO II LHD 5m3 Hydraulic Compression Garbage Truck 0

Diagram

Working Show

Our Service

Quick feedback to solve your questions
Reasonable price and good quality
Quick delivery and shipment

FAQ

Q1: What kinds of garbage trucks I can order from your company?
A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2: Have you supplied garbage truck to any overseas companies?
A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.
